tsc
Printer Barcode TSC TDP-247
8 dots / mm (203 DPI) / USB 2.0 RS-232, Parallel
Price
฿8,168
SKU: A0130953
Technical Specifications
Print Speed178 mm (7") / second
Resolution8 dots / mm (203 DPI)
DuplexNo
ADFNo
MemorySDRAM 8 MB Flash 4 MB
Scanner
Connectivity
InterfaceUSB 2.0 RS-232, Parallel
Consumables
CartridgeN/A (thermal/ribbon-based, not cartridge)
Additional Specifications
Barcode1D bar code : Code 39, Code 93, Code 128UCC, Code 128 subset A, B, C, Codabar, Interleave 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2 (5) digits add-on, MSI, PLESSEY, POSTNET, RSS-Stacked, GS1 DataBar, Code 11 China Post 2D bar code : PDF-417, Maxicode, DataMatrix, QR Code, Aztec
Dimension(W x D x H) : 20.00 x 24.00 x 16.40 cm
Display Panel1 LED (3 colors: green, amber & red)
Font8 alpha-numeric bitmap fonts Monotype Image® true type font engine with one CG Triumvirate Bold Condensed scalable font
Gross Weight3.06 KG
MediaType Continuous, die-cut, black mark, fan-fold, notched (outside wound) Width 20 ~ 112 mm (0.78" ~ 4.4") Length 10 ~ 2,286 mm (0.4" ~ 90") Thickness 0.06 ~ 0.19 mm (2.36 ~ 7.48 mil) Core diameter 25.4 ~ 76.2 mm (1" ~ 3") Media roll capacity 127 mm (5") OD *ใช้เฉพาะ Sticker Direct Thermal เท่านั้น
Net Weight1.9 kg
Package ContentsWindows labeling software CD disk Quick start guide USB cable Power cord External universal switching power supply Label spindle, fixing tab x 2, 1.5“ core adapter x 2
Package Dimension(W x D x H) : 26.00 x 35.50 x 22.50 cm
Power SupplyInput : AC 100-240V, 2.5A, 50-60Hz Output : DC 24V, 3.75A, 90W
Print Length2,286 mm (90")
Print MethodDirect Thermal
Print Width108 mm (4.25")
Ribbonไม่สามารถใช้ Rinbon พิมพ์ได้
SensorTransmissive gap sensor Black mark reflective sensor (position adjustable) Head open sensor
Short SpecDirect Thermal / Speed 7 นิ้วต่อวินาที / 203dpi / กระดาษ 0.78-4.4 นิ้ว
System SupportSAP, Oracle, WHQL 8.1, Windows, Linux, MAC X.10, Mircosoft SQL Server, Bartender, Nice Label
Volume20,767.50 cm3
Warranty:1 Year
