tp-link
Gigabit Switching Hub TP-LINK TL-SG3218XP-M2 (19",16-Port 2.5G,2-Port 10GE SFP+,8
Switch
Price
฿17,046
SKU: A0182795
Technical Specifications
Network Specifications
Device TypeSwitch
Speed10/100/1000
Build
Ports16
WarrantyLT.
Additional Specifications
Buffer Architecture• 12 Mbit
Certifications• CE, FCC, RoHS
Environment• Operating Temperature: 0–50 °C (32–122°F) • Storage Temperature: -40–70 °C (-40–158°F) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing
Fan Quantity• 2
FeaturesL3 Features • 32 IPv4/IPv6 Interfaces • Static Routing - 48 static routes • Static ARP - 128 Static Entries • Proxy ARP • Gratuitous ARP • DHCP Server • DHCP Relay - DHCP Interface Relay - DHCP VLAN Relay • DHCP L2 Relay L2 and L2+ Features • Link Aggregation - static link aggregation - 802.3ad LACP - Up to 8 aggregation groups, containing 8 ports per group • Spanning Tree Protocol - 802.1d STP - 802.1w RSTP - 802.1s MSTP - STP Security: TC Protect, BPDU Filter, Root Protect • Loopback Detection - Port based - VLAN based • Flow Control - 802.3x Flow Control - HOL Blocking Prevention • Mirroring - Port Mirroring - CPU Mirroring - One-to-One - Many-to-One - Tx/Rx/Both L2 Multicast • IGMP Snooping - IGMP v1/v2/v3 Snooping - Fast Leave - IGMP Snooping Querier - IGMP Authentication • IGMP Authentication • MLD Snooping - MLD v1/v2 Snooping - Fast Leave - MLD Snooping Querier - Static Group Config - Limited IP Multicast • MVR • Multicast Filtering: 256 profiles and 16 entries per profile Advanced Features • Automatic Device Discovery • Batch Configuration • Batch Firmware Upgrading • Intelligent Network Monitoring • Abnormal Event Warnings • Unified Configuration • Reboot Schedule
Forwarding Rate• 89.28 Mpps
Jumbo Frame• 9 KB
Led Indicators• YES
Mac Address Table• 16 K
Management• Omada Cloud-Based Controller • Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software Controller • Web-based GUI • Command Line Interface (CLI) through the console port, telnet • SNMP v1/v2c/v3 - Trap/Inform - RMON (1,2,3,9 groups) • SDM Template • DHCP/BOOTP Client • 802.1ab LLDP/LLDP-MED • DHCP AutoInstall • Dual Image, Dual Configuration • CPU Monitoring • Cable Diagnostics • EEE • Password Recovery • SNTP • System Log
Material• Metal
Network Interface• 16× 2.5 Gbps RJ45 Ports (8 PoE Port Power Budget 240 W) • 2× 10G SFP+ Slots • 1× RJ45 Console Port
Package Contents• SG3218XP-M2 Switch • Power Cord • Quick Installation Guide • Rackmount Kit • Rubber Feet
Poe• Standard: 802.3at/af compliant • PoE+ Ports(802.3at PoE): 8 Ports, up to 30 W per port • Power Budget: 240 W
Power Consumption• Max. Power Consumption : 299.4 W (110V/60Hz)(with 240 W PD connected) • Max. Heat Dissipation : 1021.64 BTU/h (110 V/60 Hz)(with 240 W PD connected)
Power Supply• 100-240 V AC~50/60 Hz
Security• IP-MAC-Port Binding - 512 Entries - DHCP Snooping - ARP Inspection - IPv4 Source Guard: 100 Entries • IPv6-MAC-Port Binding - 512 Entries - DHCPv6 Snooping - ND Detection - IPv6 Source Guard: 100 Entries • DoS Defend • Static/Dynamic Port Security - Up to 64 MAC addresses per port • Broadcast/Multicast/Unicast Storm Control - kbps/ratio control mode • 802.1X - Port base authentication - Mac base authentication - VLAN Assignment - MAB - Guest VLAN - Support Radius authentication andaccountability • AAA (including TACACS+) • Port Isolation • Secure web management through HTTPS with SSLv3/TLS 1.2 • Secure Command Line Interface (CLI) management with SSHv1/SSHv2 • IP/Port/MAC based access control
Standards And Protocols• IEEE 802.3/3u/3ab/3bz/3ae (2.5G/10G), 802.3af/at (PoE+), 802.1Q/1p/1D/1w/1s/3ad/1X
Switching Capacity• 120 Gbps
Usb Port• 1× Micro-USB Console Port
Vlan• VLAN Group - Max 4K VLAN Groups • 802.1Q Tagged VLAN • MAC VLAN: 256 Entries • Protocol VLAN: Protocol Template 16, Protocol VLAN 16 • GVRP • VLAN VPN (QinQ) - Port-Based QinQ - Selective QinQ • Voice VLAN
Warranty:LT.
