tp-link
Gigabit Switching Hub TP-LINK TL-ES220GMP (17" 16 PoE + 2 RJ45 + 2 SFP)
Switch / N/A (Wired)
Price
฿6,170
SKU: A0181702
Technical Specifications
Network Specifications
Device TypeSwitch
Wi-Fi StandardN/A (Wired)
Speed10/100/1000
Build
Ports• 16× 10/100/1000 Mbps PoE+ (Power Budget 250W), • 2× 10/100/1000 Mbps RJ45 Port, • 2× Gi…
AntennaNone (Internal)
WarrantyLT.
Additional Specifications
Buffer Architecture• 4 Mbit
CertificationsFCC, CE, RoHS
Dimension(W x D x H) : 44.00 x 18.00 x 44.00 cm
Environment• Operating Temperature: -5°C~50°C (23°F~122°F) • Storage Temperature: -40°C~70°C (-40°F~158°F) • Operating Humidity: 10%~90% non-condensing • Storage Humidity: 5%~90% non-condensing
Fan Quantity• 2
Features• Static Link Aggregation • Loop Prevention / Loopback Detection • Flow Control : 802.3x Flow Control • Mirroring : Port Mirroring , One-to-One, Many-to-One, Ingress/Egress/Both • Port Statistics : Port Mirror Status, Traffic Statistics • 802.1ab LLDP • IGMP Snooping : IGMP v1/v2/v3 Snooping, Fast Leave
Forwarding Rate• 29.76 Mpps
Gross Weight3.34 KG
Jumbo Frame• 15 KB
Led Indicators• YES
Mac Address Table• 8K
Management• Omada Cloud-Based Controller • Omada Hardware Controller • Omada Software Controller • Web-based GUI • DHCP Client • Cable Diagnostics • Automatic Device Discovery • Batch Configuration • Batch Firmware Upgrading • Unified Configuration
Material• Metal
Net Weight0 kg
Network Interface• 16× 10/100/1000 Mbps PoE+ (Power Budget 250W) • 2× 10/100/1000 Mbps RJ45 Port • 2× Gigabit SFP Slot
Package Contents• ES220GMP • Power Cord • Mounting Brackets • Rubber Feet • Screws • Installation Guide
Package Dimension(W x D x H) : 28.00 x 54.00 x 8.00 cm
Poe• Standard: 802.3af PoE and 802.3at PoE+ compliant • PoE Ports: 16 ports • PoE Budget: 250W available for all PoE+ ports, 30W max per port • Fast PoE & Perpetual PoE • PoE Auto Recovery • Up to 250m PoE transmission distance
Power Supply• 100–240V AC, 50/60Hz
Standards And Protocols• IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.3af, 802.3at, 802.1p, 802.1Q, 802.1ab
Switching Capacity• 40Gbps
Transmission Method• Store-And-Forward
Vlan• MTU VLAN • Port-Based VLAN • 802.1Q Tag VLAN - Max 32 VLAN Groups - 4K VID
Volume12,096.00 cm3
Warranty:LT.
